Home Motors brushless rear hub motor 24v 36v 48v 2500w 350w with disc function made by chinese factory

brushless rear hub motor 24v 36v 48v 2500w 350w with disc function made by chinese factory

paragraph1

Color

Black

Silver

Samples

≥1pcs

price

Depend on configuration

Quantity:

库存： 0

Inquire

Add to Basket

Product Description

Basic Parameters

Position	Rear	Magnet Poles(2P)	10
Construction	Gear	Operating temperature (℃ )	-20-45
Rated Voltage(V)	24 / 36 /48	Surface color	Black / Silver
Rated Power (W)	250 / 350	Dropout(mm)	160
Weight (KG)	3	Drive and Freewheel	6s-8s
Reduction Ratio	1 : 4.4	Brake type	Strut / V Brake
Max torque(N.m)	42	Efficiency (%)	≥ 80
Wheel size (Inch)	16-28	Cable position	Shaft center Right
Spoke specification	36H-12G/13G	Noise grade (db)	≤ 45
Rated speed(km/h)	25-32	IP grade	54

Product advantages

1	Long service life (bearing life), long maintenance cycle; Simple and convenient maintenance;
2	There is no mechanical commutator inside to prevent dust from entering the motor, with high reliability;
3	The overload capacity is strong, meeting the needs of the vehicle's protruding locked rotor, and the motor rotor has a high permanent magnetic field;
4	Excellent starting performance, energy consumption without hysteresis damping, and high torque climbing capability;
5	High working efficiency, low power consumption and long driving distance;
6	Superior waterproof performance;
7	There are many driving modes, which can meet most loading requirements of the market;
8	High performance price ratio of motor;
9	Low noise and reliable operation
