Home Motors Electric mountain bike 20 inch Integrated wheel 36v 48V 250w 350W 500w high speed power motor electric bicycle motor

Electric mountain bike 20 inch Integrated wheel 36v 48V 250w 350W 500w high speed power motor electric bicycle motor

paragraph1

Color

Black

Silver

Samples

≥1pcs

price

Depend on configuration

Quantity:

库存： 0

Inquire

Add to Basket

Product Description

Basic Parameters

Position	Rear	Operating temperature (℃ )	-20-45
Construction	Gear	Surface color	Black / Silver
Rated Voltage(V)	36 /48	Dropout(mm)	150
Rated Power (W)	250 / 350 / 500	Drive and Freewheel	6s-8s
Weight (KG)	6.5	Brake type	V / Disc Brake
Reduction Ratio	1 : 5	Efficiency (%)	≥ 80
Max torque(N.m)	65	Cable position	Shaft center Right
Wheel size (Inch)	20inch * (2.5-3.0)	Noise grade (db)	≤ 45
Rated speed(km/h)	25-35	IP grade	54
Magnet Poles(2P)	10	Salt spray test standard(h)	24/96

Product advantages

1	Long service life (bearing life), long maintenance cycle; Simple and convenient maintenance;
2	There is no mechanical commutator inside to prevent dust from entering the motor, with high reliability;
3	The overload capacity is strong, meeting the needs of the vehicle's protruding locked rotor, and the motor rotor has a high permanent magnetic field;
4	Excellent starting performance, energy consumption without hysteresis damping, and high torque climbing capability;
5	High working efficiency, low power consumption and long driving distance;
6	Superior waterproof performance;
7	There are many driving modes, which can meet most loading requirements of the market;
8	High performance price ratio of motor;
9	Low noise and reliable operation
