Home Motors 24v36V/48V 250W 350W Front Wheel Motor Electric Bike Hub Motor eBike Engine Mount

24v36V/48V 250W 350W Front Wheel Motor Electric Bike Hub Motor eBike Engine Mount

paragraph1

Color

Black

Silver

Samples

≥1pcs

price

Depend on configuration

Quantity:

库存： 0

Inquire

Add to Basket

Product Description

Basic Parameters

Position	Front	Magnet Poles(2P)	10
Construction	Gear	Operating temperature (℃ )	-20-45
Rated Voltage(V)	24 / 36 /48	Surface color	Black / Silver
Rated Power (W)	250 / 350	Dropout(mm)	100
Weight (KG)	3	Brake type	V / Disc Brake
Reduction Ratio	1 : 4.4	Efficiency (%)	≥ 80
Max torque(N.m)	42	Cable position	Shaft center Right
Wheel size (Inch)	16-28	Noise grade (db)	≤ 45
Spoke specification	36H-12G/13G	IP grade	54
Rated speed(km/h)	25-32	Salt spray test standard(h)	24/96

Product advantages

1	Long service life (bearing life), long maintenance cycle; Simple and convenient maintenance;
2	There is no mechanical commutator inside to prevent dust from entering the motor, with high reliability;
3	The overload capacity is strong, meeting the needs of the vehicle's protruding locked rotor, and the motor rotor has a high permanent magnetic field;
4	Excellent starting performance, energy consumption without hysteresis damping, and high torque climbing capability;
5	High working efficiency, low power consumption and long driving distance;
6	Superior waterproof performance;
7	There are many driving modes, which can meet most loading requirements of the market;
8	High performance price ratio of motor;
9	Low noise and reliable operation
